II37464N50 Multi-circuit Protection Valve1 KNORR BREMSE FOUR CIRCUIT PROT VALVE
Technical Information:
Air Inlet port(s) size: M16x1,5
Air Delivery port(s) size:
21,22,23,24,25,26: Voss NG12 M22x1,5
Circuit 1: Feedback with Bypass
Circuit 1 - Open/close pressure [bar]:
7,0-0,3/ >=4,5
Circuit 1 - Pressure Limiting [bar]: Not included
Circuit 2: Feedback with Bypass
Circuit 2 - Open/close pressure [bar]:
7,0-0,3/ >=4,5
Circuit 2 - Pressure Limiting [bar]: Not included
Circuit 3 - Open/close pressure [bar]:
7,5-0,3/ >=4,5
Circuit 3 - Pressure Limiting [bar]: 8,5 +0,0/-0,4
Circuit 4: Feedback with Bypass
Circuit 4 - Open/close pressure [bar]:
7,0-0,3/ >=4,5
Circuit 4 - Pressure Limiting [bar]: Not included
Bleed-back safety feature:
Controlled by Circuit 1
Circuits' supply:
Internal series supply from 1
With Electrical pressure sensing: Yes
Viewed
1) Installation instructions are not included in all instances. If you or your customers require installation instructions, please ask before ordering. All products should be installed only according to the intended purpose and only by specialist trained personnel. 2) The parts offered are reproductions. The specified original replacement parts numbers are for the purpose of comparison. This information has been complied to the best of our abilities, but errors cannot be excluded. We are unable to accept liability for the accuracy of the specifications. The capability for use must be checked before each installation.
